DALY SMART BMS LFP 23S 80A

DALY SMART BMS LFP 23S 80A

The DALY Smart BMS LFP 23S 80A is a communication-capable battery management system for compatible twenty-three-series LiFePO4 battery packs. A 23S LFP pack uses twenty-three nominal 3.2V cell groups in series, placing the battery in the approximately 73.6V nominal class. The 80A current designation makes this model relevant to higher-power energy-storage, EV and industrial battery systems when the cells, busbars, wiring, connectors, fuse protection and thermal design are all sized for the same operating current.

A smart BMS combines the core protection role of a battery management system with monitoring and communication functions. The BMS tracks cell-group voltage and other operating information, then controls the charge/discharge path according to programmed protection logic. DALY's smart portfolio includes functions such as overcharge, over-discharge, over-current, short-circuit and temperature protection, together with app or host communication on supported models. Exact trigger values and sensor counts remain model-specific.

For a 23S pack, wiring accuracy is especially important because the balance harness carries many cumulative voltage steps. A single misplaced cell-tap wire can expose the BMS input to the wrong voltage. The 80A rating also requires low-resistance current paths, appropriately crimped cable lugs and a pack enclosure that allows heat generated by the BMS and cables to dissipate.

Use this product only with a 23S LiFePO4 battery. Confirm whether the stocked unit is the CAN version, what communication cable or module is included, which inverter protocols are supported, and whether the BMS uses common-port or another architecture. If the battery is intended for an inverter or ESS controller, communication compatibility should be checked against the exact inverter model rather than assuming that any CAN-equipped BMS will communicate automatically.

Applications

1. 23S LiFePO4 energy-storage batteries

2. Solar and hybrid-inverter battery banks

3. EV and e-rickshaw battery systems

4. Industrial UPS and backup power

5. High-voltage custom LFP battery packs

6. Battery R&D and smart monitoring projects

Installation Guide

Connect the 23 balance leads in the correct sequence and verify every voltage step before inserting the harness. Use the recommended high-current cable size, lugs and fuse protection for the final pack. Mount the BMS on an insulated surface with enough airflow for thermal management. Connect CAN/UART/RS485 accessories only to the port intended for that interface. During commissioning, verify cell count, chemistry, current limits, protection settings and communication data before applying the full system load.
